CLB-307 Full Extension with Quick Disconnect Ball Bearing Slide
Your request has been sent! A representative will contact you as soon as possible.
Product Information
Product Image
Model
CLB-307
Temperature
-45 to 150 ºF
Load Capacity Range
75-175 lbs
Load Capacity Notes
Load capacity is based on one set of slides at full extension with load (center of gravity) centered between the slides and at midpoint of the slide (chassis section). Load capacities have a 100% (static load) safety factor at full extension. The slides will support more than the stated capacities but are not designed to be operated at capacities greater than those stated.
Finish
Clear zinc commercial plating. Other finishes available upon request.
Spec Sheets
Installation Instructions
Image Gallery
Product Notes
- 0.76" wide x 1.35" tall, sliding section thickness is 0.64"
- 100% extension
- Right hand and left hand slides are identical. Set contains 2 slides.
- Flat-mounting hardware included:
- #8-32 x 3/8" Phillips pan head screws (0.094" max head height)
- self-locking nuts
- Quick disconnect feature: inner profile section locks out and separates from slide for easy mounting.
- 14 ga CRS
- Recommended slide length is 1.0" less than the rail depth setting.
- Slide finish is clear zinc commercial plating.
- Custom hole patterns are available.
- Other non-standard options which are available include: special marking, special extensions, special finishes, lock-in, and complete design changes per request. Factory as these options will require a special reference number to assure receipt of specified options.
Product Models
Showing Results: 1 - 19 of 19
| Item # | Slide Length - A (in) | Forward Extension - B | Load Capacity (lbs) | GDI Reference # |
|---|---|---|---|---|
| CLB-307-12 | 12 | 13 | 175 | CC7602-00-0120 |
| CLB-307-13 | 13 | 14 | 175 | CC7602-00-0130 |
| CLB-307-14 | 14 | 15 | 170 | CC7602-00-0140 |
| CLB-307-15 | 15 | 16 | 165 | CC7602-00-0150 |
| CLB-307-16 | 16 | 17 | 160 | CC7602-00-0160 |
| CLB-307-17 | 17 | 18 | 155 | CC7602-00-0170 |
| CLB-307-18 | 18 | 19 | 150 | CC7602-00-0180 |
| CLB-307-19 | 19 | 20 | 150 | CC7602-00-0190 |
| CLB-307-20 | 20 | 21 | 145 | CC7602-00-0200 |
| CLB-307-21 | 21 | 22 | 140 | CC7602-00-0210 |
| CLB-307-22 | 22 | 23 | 130 | CC7602-00-0220 |
| CLB-307-23 | 23 | 24 | 125 | CC7602-00-0230 |
| CLB-307-24 | 24 | 25 | 115 | CC7602-00-0240 |
| CLB-307-25 | 25 | 26 | 110 | CC7602-00-0250 |
| CLB-307-26 | 26 | 27 | 105 | CC7602-00-0260 |
| CLB-307-27 | 27 | 28 | 100 | CC7602-00-0270 |
| CLB-307-28 | 28 | 29 | 90 | CC7602-00-0280 |
| CLB-307-29 | 29 | 30 | 85 | CC7602-00-0290 |
| CLB-307-30 | 30 | 31 | 75 | CC7602-00-0300 |
